We Compared 6 Chicken Nipple Waterers on Mount Style

Horizontal or vertical decides where your water can sit and where the drips land. We compared six chicken nipple waterers on mount style and cost per nipple.

Published Prices and stock checked 7 min read

A single hen standing in a grassy backyard run in bright daylight
Photo: www.metaphoricalplatypus.com / Wikimedia Commons, CC BY 2.0

Nipple waterers all look the same in a listing photo. They are not the same, and the difference is decided before you have drilled a single hole. It is mount style: horizontal side mount against vertical screw in.

A horizontal nipple threads into the side wall of a bucket, an inch or two up from the base. The bucket then sits flat on a block or a paver at bird height, you use nearly all the water in it, and the drip falls straight down onto the ground. A vertical screw in nipple goes into the bottom of a bucket or the underside of a PVC run, which means the bucket has to be lifted onto a stand at head height and every drip lands on the bedding below.

Five of the six here are horizontal. Only the KISEER pack is the screw style, and it is in this guide because a vertical run through PVC pipe is a genuinely good setup if that is what you are building.

The second half of the mount spec is the hole you drill. An oversize hole in a bucket wall weeps forever, and tape does not fix it. That is why the winner here is not the cheapest per nipple: it is the one that ships the matching drill bit. Cost per nipple runs from $0.29 to $5.57 across this group, so read that column carefully before the sticker price.

Our picks at a glance

Every product below wins one specific situation. Pick the row that matches your flock, your yard and your budget rather than reading top to bottom.

Compare every pick side by side

Swipe the table sideways to see every column on a phone.

6 chicken nipple waterer compared on the specs that change the buying decision. Prices and availability checked 2026-08-08.
Product Award Price band Mount StylePack QuantityMaterialBirds Per NippleIncluded ExtrasListing Note Best use case Buy link
Eggluuz 8-Pack Best Overall for a Bucket Under $30 Horizontal side mount8 nipplesDurable sturdy plastic and stainless steelNot stated, listed as suitable for chicks over 2 weeks and adult birdsDrill bit, wingnutListing says the nipples 'will not gum up or freeze in winter'. No open nipple can hold that below freezing without a heat source Anyone converting a food grade 5 gallon bucket into a nipple waterer for… Check price for Eggluuz Chicken Waterer Nipple Horizontal Side Mount Automatic Nipples Drinker for Chickens 8 Pack on Amazon
Hedume 50-Pack Best for Kitting Out a Whole Flock Under $30 Horizontal side mount, 8 mm thread, 1.4 in wide and 1.4 in tall50 nipplesABS plastic and stainless steelMaker suggests 1 nipple per 4 birdsNone stated, drill your own hole and hand tightenNone Keepers fitting out several buckets, a large flock or multiple coops who… Check price for Hedume 50 Pack Horizontal Poultry Water Nipples, Automatic Side Mount Chicken Drinkers for Ducks, Quail and Other Poultry on Amazon
senylanhxy Tee Kit Best If You Do Not Want to Drill Under $30 Horizontal side mount, screws onto 1/2 in PVC tee fittings15 nipplesABS plastic and stainless steelNot stated15 tee fittings, 15 sealing gaskets, 1 waterproof tapeNone Keepers plumbing a half inch PVC watering line who would rather make thre… Check price for 15-Pack Horizontal Chicken Nipples Waterer with 1/2" PVC Tee Fittings, Automatic Poultry Waterer Kit for DIY Chicken Duck Quail Watering System, Side Mount Drinker on Amazon
Farm Basics Stainless Best All Stainless Build Under $30 Horizontal mount stem with 1/8 in MPT threads, PVC tees or wing nuts8 nipplesStainless steelNot statedWing nutsNone Keepers who have already had plastic nipple bodies crack at the thread an… Check price for Farm Basics Stainless Steel Poultry Drinker Nipple (8Pack) for Chickens, Chicks, Quail on Amazon
MAVGZUL DIY System Best Ready Made Watering Line $30 to $60 Horizontal nipples on 1/2 in PVC tee fittings along a piped run8 nipples with tee fittingsNot stated, PVC pipe with a stainless steel hose and brass connectorNot statedHole saw, brass connector, stainless steel hose, shut-off valve, glue, adapter, tape, 10 PVC pipes, end cap, 8 u-straps with screws. Drill and bucket not includedNone Anyone building a piped watering run along a coop wall who would rather o… Check price for DIY Chicken Watering System - 1/2" PVC Tee Fittings and Chicken Waterer Nipples with PVC Pipe, Stainless Steel Hose, Automatic Chicken Waterer Feeder Kit for Chicken, Duck, Quail on Amazon
KISEER 30-Pack Best for a Vertical PVC Install Under $30 Screw style, installed vertically into PVC pipe or a reducing tee30 nipplesNot statedMaker recommends 3 birds per nippleNone, nipples only, maker says no drip cup is requiredNone Keepers plumbing a vertical PVC line under a raised reservoir, where the… Check price for KISEER 30 Pack Automatic Chicken Waterer Poultry Water Nipple Drinker Feeders Hen Duck Screw Style on Amazon

The full reviews

Each review below follows the same order: what it is, why it won its category, how it behaves in real use, and who should buy something else.

1 Best Overall for a Bucket

Eggluuz Chicken Waterer Nipple Horizontal Side Mount Automatic Nipples Drinker for Chickens 8 Pack

Eggluuz Chicken Waterer Nipple Horizontal Side Mount Automatic Nipples Drin… (Eggluuz 8-Pack)

The only pack here that ships the matching drill bit and a wingnut, which is exactly where nipple installs fail. At $0.75 a nipple it costs more than a Hedume and saves you the bucket you would otherwise drill oversize.

What we liked

  • Ships the matching drill bit, so the hole and the thread are sized to each other
  • Wingnut included for a proper clamped seal rather than hand tightening alone
  • Horizontal side mount, so the bucket sits flat on a block and you use nearly all the water
  • Stainless steel pin in a sturdy plastic body, the standard combination that lasts
  • Eight nipples covers a flock of about 32 birds at one nipple per four

What we did not

  • The listing claims the nipples will not gum up or freeze in winter, and no open nipple can hold water in a metal stem above freezing without a heat source
  • No birds per nipple figure is stated, so there is nothing from the maker to size a pack against your flock
  • At $0.75 a nipple it is more than twice the cost per nipple of the Hedume pack, which is the same horizontal design

Key specifications

Size
8 Pack
Colour
Orange
Mount Style
Horizontal side mount
Pack Quantity
8 nipples
Material
Durable sturdy plastic and stainless steel
Birds Per Nipple
Not stated, listed as suitable for chicks over 2 weeks and adult birds
Included Extras
Drill bit, wingnut
Listing Note
Listing says the nipples 'will not gum up or freeze in winter'. No open nipple can hold that below freezing without a heat source

Why the Eggluuz 8-Pack wins this category

Not on price and not on materials. It wins on the drill bit in the box.

Nipple waterers fail at the hole. The nipple threads into plastic, and if the hole is even slightly oversize the thread has nothing to grip and the seal never seats properly. The bucket then weeps a slow trickle all day, the bedding under it stays wet, and tape wrapped round the thread buys a week at best. You have spent a bucket to learn a lesson. The Eggluuz 8-Pack is the only pack in this guide that ships the bit sized to its own thread, and that removes the whole problem.

The wingnut matters for the same reason. It clamps the nipple against the bucket wall rather than relying on how hard you can twist it with wet hands, which gives a more consistent seal.

The mount style is right too. Horizontal side mount means the nipple sits an inch or two above the base of the bucket, so the bucket stands flat on a paver, settled grit stays below the valve, and drips fall clear of the base.

Living with the Eggluuz 8-Pack

Mark the holes a few inches up from the bottom of the bucket and drill with the supplied bit. Fit the nipple, snug the wingnut, then fill the bucket and watch it for 10 minutes before you put it in the run. Weeping at a thread shows up in that window, and a bucket is far easier to redrill on day one.

Eight nipples covers a flock of around 32 birds at our working figure of one per four, so most keepers will split the pack across two buckets at opposite ends of the run. Two per bucket minimum is the rule worth keeping, because a single valve that jams shut leaves birds with no water.

Then teach them. Tap the pin until a drop hangs on it and hold it to a beak. Two or three birds learning is enough for the rest to copy, and the old waterer should stay out for 48 hours.

Eggluuz says these suit chicks over two weeks as well as adult birds, so a brooder can share the same hardware if the height is set for the smallest bird.

Where the Eggluuz 8-Pack falls short

The freezing claim is the honest complaint. The listing states the nipples will not gum up or freeze in winter. We record it and we do not repeat it. Every open nipple holds a small amount of water inside a thin metal stem exposed to the air, and that water freezes at 32 F with nothing warming it. Treat this as a summer to autumn solution and budget for a heated base if your winter goes below freezing.

The cost per nipple is the second issue. At $0.75 each this is more than twice the Hedume figure of $0.29 for the same horizontal design. What you are buying is the bit and the wingnut, so if you already own the right size bit the maths goes the other way.

And there is no birds per nipple figure anywhere on the listing, which leaves you sizing the pack yourself.

Research based, not hands-on

Assessed on the stated mount style, materials, included hardware and pack quantity from the listing, on cost per nipple against the other five packs, and on the known failure mode of an oversize hole in a bucket wall.

Recommendation based on: Manufacturer stated mount style, materials, pack quantity and included extras from the live Amazon listing; Cost per nipple comparison against the other five nipple packs in this guide; Published guidance on horizontal nipple installation and on freezing in open drinker stems.

Best for
Anyone converting a food grade 5 gallon bucket into a nipple waterer for the first time and drilling their own holes.
Skip it if
You are fitting out a whole flock or several buckets, because the cost per nipple is high next to a bulk pack.
The limitation to plan around
Nothing here solves winter. The metal stem holds a small amount of water in open air and freezes at 32 F, so a heated base is a separate purchase in a cold climate.

2 Best for Kitting Out a Whole Flock

Hedume 50 Pack Horizontal Poultry Water Nipples, Automatic Side Mount Chicken Drinkers for Ducks, Quail and Other Poultry

Hedume 50 Pack Horizontal Poultry Water Nipples (Hedume 50-Pack)

Fifty horizontal nipples at $0.29 each, the lowest cost per nipple in this guide. You supply the 8 mm bit and you tighten them by hand, which is the whole difference between this and the pack that wins.

What we liked

  • About $0.29 a nipple, the cheapest per nipple cost of the six packs here
  • Fifty nipples covers several buckets, a brooder and spares from one order
  • Horizontal side mount, so buckets sit flat on a block instead of on a raised stand
  • ABS plastic body with a stainless steel pin, the standard build across this category
  • One of only two packs here that states a birds per nipple figure, at four birds per nipple

What we did not

  • No drill bit is included and the thread is 8 mm, so an oversize hole in a bucket wall will weep for the life of that bucket
  • Hand tightening with no wingnut gives a less consistent seal against a curved bucket wall than a clamped fitting
  • Fifty nipples is far more than a backyard flock needs, so most of the pack sits in a drawer for years

Key specifications

Colour
Red
Mount Style
Horizontal side mount, 8 mm thread, 1.4 in wide and 1.4 in tall
Pack Quantity
50 nipples
Material
ABS plastic and stainless steel
Birds Per Nipple
Maker suggests 1 nipple per 4 birds
Included Extras
None stated, drill your own hole and hand tighten
Listing Note
None

Why the Hedume 50-Pack wins this category

Volume at the right price. Fifty horizontal nipples for $14.39 works out at about $0.29 each, which is the lowest cost per nipple on this page. If you are watering a flock of 30 across three buckets, or running a brooder line and a run line and keeping spares, this is the pack that makes it cheap.

The design is not a compromise for the money. It is a horizontal side mount with a stainless pin in an ABS body, the same arrangement as the winner, at 1.4 in wide and 1.4 in tall with an 8 mm thread. It goes into the wall of a bucket the same way, and the bucket sits flat on a block the same way.

Hedume is also one of only two makers here who put a number on flock size, suggesting one nipple per four birds. That happens to match the working figure we use, and it means a 50 pack in theory waters 200 birds.

Living with the Hedume 50-Pack

Buy or borrow an 8 mm bit first and try it on a scrap bucket. That is the whole install in one sentence. Drill the hole a few inches above the base so settled grit stays below the valve, thread the nipple in by hand, then fill and watch for 10 minutes.

Hand tightening against a curved bucket wall takes a little care. Get the nipple seated square rather than at an angle, and stop when it is snug rather than forcing it, because overtightening into thin plastic strips the hole and leaves you no second chance.

Fit at least two per bucket. At this price there is no reason not to, and the second one is your insurance against a valve jamming shut on a hot day.

Store the rest somewhere dry and labelled. You will forget what thread size they are.

Where the Hedume 50-Pack falls short

Nothing ships with them. No bit, no wingnut, no gasket. Hedume states the thread is 8 mm and leaves the rest to you, and the hole is precisely where nipple installs go wrong. A hole a shade too large weeps constantly, the bedding under the bucket stays wet, and tape does not fix it. If you do not already own the bit, the saving over the Eggluuz pack disappears the first time you ruin a bucket.

Hand tightening is the second gap. There is no wingnut to clamp the fitting against the wall, so the seal depends on the thread biting cleanly into the plastic.

And 50 is a lot. For four or five hens you need two or three nipples, so you are buying a lifetime supply to save a few dollars. That is fine if you have somewhere to keep them and a use in mind, and pointless if you do not.

Research based, not hands-on

Assessed on the stated thread size, mount style, dimensions, materials and birds per nipple figure from the listing, and on cost per nipple worked out from the price and the 50 piece quantity against the other five packs.

Recommendation based on: Manufacturer stated mount style, thread size, dimensions, materials and pack quantity from the live Amazon listing; Cost per nipple comparison against the other five nipple packs in this guide; Published guidance on horizontal nipple installation and hole sizing in plastic buckets.

Best for
Keepers fitting out several buckets, a large flock or multiple coops who already own a set of metric drill bits.
Skip it if
This is your first nipple install and you do not have an 8 mm bit, because the hole is where these go wrong.
The limitation to plan around
The 8 mm thread has to meet a hole you cut yourself. Test the fit on a scrap bucket before you touch the one you intend to use.

3 Best If You Do Not Want to Drill

15-Pack Horizontal Chicken Nipples Waterer with 1/2" PVC Tee Fittings, Automatic Poultry Waterer Kit for DIY Chicken Duck Quail Watering System, Side Mount Drinker

senylanhxy -Pack Horizontal Chicken Nipples Waterer with 1/2" PVC Tee Fittings (senylanhxy Tee Kit)

Fifteen horizontal nipples already matched to half inch PVC tee fittings, with gaskets and tape in the box. It turns the seal from a hole you cut into a threaded joint, at $1.20 a nipple.

What we liked

  • No drilling at all, because each nipple screws into a supplied half inch PVC tee
  • Fifteen sealing gaskets included, one per fitting, which is the part people forget to buy
  • Waterproof tape supplied for the threaded joints
  • Horizontal side mount, so the pipe run can sit low and drips fall clear
  • ABS plastic body with a stainless steel pin, the same build as the cheaper bulk packs

What we did not

  • You still have to buy PVC pipe, elbows, a cap and a reservoir separately, so the kit price is not the system price
  • A tee fitting run is fixed once glued, so moving a drinker later means cutting and rebuilding the line
  • No birds per nipple figure is stated, so nothing from the maker helps you size the run to your flock

Key specifications

Colour
red
Mount Style
Horizontal side mount, screws onto 1/2 in PVC tee fittings
Pack Quantity
15 nipples
Material
ABS plastic and stainless steel
Birds Per Nipple
Not stated
Included Extras
15 tee fittings, 15 sealing gaskets, 1 waterproof tape
Listing Note
None

Why the senylanhxy Tee Kit wins this category

It removes the step that ruins nipple installs. Drilling a bucket wall is a one shot operation, and a hole a shade too big weeps for the life of the bucket. The senylanhxy Tee Kit sidesteps that entirely by giving you 15 nipples that thread into 15 supplied half inch PVC tees. The seal becomes a threaded joint with a gasket behind it, which is a repeatable, correctable connection rather than a cut.

The kit is thought through. Fifteen gaskets means one per fitting rather than a handful, and the waterproof tape is in the box, which is the item people discover they need halfway through the job.

The nipples themselves are horizontal side mount with a stainless pin in an ABS body, so a pipe run sits at bird height along the run wall rather than overhead. Drips fall clear of the pipe instead of tracking back along it.

At $17.98 for 15 that is about $1.20 a nipple, more than the plain bulk packs at $0.29 and $0.33 and well under the $5.57 a nipple the MAVGZUL full system works out at.

Living with the senylanhxy Tee Kit

Lay the run out dry before you glue anything. Space the tees so each nipple sits slightly above the back of your shortest hen, and put them where you can reach every one for cleaning.

Tape and gasket every joint as you go, then pressure test the whole line with water before the birds see it. A single weeping tee in the middle of a run is a wet patch you will be looking at all season.

Feed it from a bucket on a block at one end. The line only needs a few inches of head to work, so the reservoir does not have to be high, which is the practical advantage of horizontal nipples over vertical ones.

Then teach the flock. Tap the pin until a drop hangs and hold it to a beak. Nobody finds a nipple on their own.

Where the senylanhxy Tee Kit falls short

The kit is not the system. You get nipples, tees, gaskets and tape. You do not get pipe, elbows, an end cap, a reservoir or the glue, and those add up. Compare the finished cost against the MAVGZUL kit, which ships the pipe, the straps, a hole saw and a shut off valve, before deciding this is the cheaper route.

A glued run is also a permanent decision. Once the cement has set, moving a drinker two feet along means cutting the pipe and fitting a coupling. Buckets with drilled nipples can be picked up and moved anywhere.

And senylanhxy states no birds per nipple figure, so use the working number of one per four birds and at least two on any line.

Research based, not hands-on

Assessed on the stated mount style, fitting compatibility, included gaskets and tape from the listing, and on cost per nipple worked out from the price and the 15 piece quantity against the other five packs here.

Recommendation based on: Manufacturer stated mount style, fitting type, included extras and pack quantity from the live Amazon listing; Cost per nipple comparison against the other five nipple packs in this guide; Published guidance on PVC watering line assembly and threaded joint sealing.

Best for
Keepers plumbing a half inch PVC watering line who would rather make threaded joints than drill and seal a bucket.
Skip it if
You want to convert a bucket you already own, because these are built around tee fittings rather than a flat wall.
The limitation to plan around
The kit is nipples and fittings only. Pipe, elbows, an end cap and the water source are all on you, so price the full build before you commit.

4 Best All Stainless Build

Farm Basics Stainless Steel Poultry Drinker Nipple (8Pack) for Chickens, Chicks, Quail

Farm Basics Stainless Steel Poultry Drinker Nipple (8Pack) for Chickens

The only fully stainless nipple here, with an eighth inch MPT thread that takes PVC tees or the supplied wing nuts. At about $2.50 each it costs roughly eight times a Hedume and does the same job unless split plastic bodies are a failure you have had.

What we liked

  • Stainless steel throughout rather than a steel pin in a plastic body
  • No plastic body to go brittle and split at the thread after years in hard sun
  • Standard eighth inch MPT thread, so it takes PVC tees or a bucket wall with the supplied wing nuts
  • Wing nuts included, so the fitting clamps rather than relying on hand tightening
  • Suits chickens, chicks and quail from the same eight piece pack

What we did not

  • About $2.50 a nipple against $0.29 for a Hedume, roughly eight times the cost for the same water in the same place
  • No drill bit is included, and the eighth inch MPT thread still needs a hole matched to it, so the leak risk in a bucket wall is unchanged
  • Stainless pulls heat out of the small volume of water in the stem faster than plastic, so it ices up sooner rather than later in a freeze

Key specifications

Dimensions
6 x 6 x 2 in (L x W x H)
Colour
BLACK
Mount Style
Horizontal mount stem with 1/8 in MPT threads, PVC tees or wing nuts
Pack Quantity
8 nipples
Material
Stainless steel
Birds Per Nipple
Not stated
Included Extras
Wing nuts
Listing Note
None

Why the Farm Basics Stainless wins this category

Every other nipple in this guide is a stainless pin in a plastic body. The Farm Basics Stainless is metal all the way through, and that removes one specific failure: a plastic body that goes brittle in years of hard sun and splits at the thread where it is under load. It is not a common failure, but it is a real one, and it always happens with a full bucket.

The thread is a standard eighth inch MPT, which is more flexible than a proprietary size. It screws into a PVC tee if you are plumbing a run, or through a bucket wall with the supplied wing nuts if you are converting a bucket. Wing nuts in the box also mean the fitting clamps against the wall rather than depending on how hard you can twist it.

Farm Basics lists it for chickens, chicks and quail, so the same eight nipples cover a brooder and a run.

Living with the Farm Basics Stainless

Decide the mount before you order the rest of the parts. On a bucket, drill for the eighth inch MPT thread and clamp with a wing nut a few inches above the base. On a PVC line, thread it into a tee with tape and skip the drilling entirely.

Eight nipples covers about 32 birds at one nipple per four, which is a reasonable pack size for most backyard flocks. Fit at least two on any single bucket so a jammed valve is not a flock with no water.

Metal shows scale in hard water more visibly than plastic does. A wipe over the stem when you refill keeps the pin moving freely, and a pin that sticks is the most common cause of a nipple that stops giving water.

Train the birds the same way as any other nipple. Tap the pin, hold the drop to a beak, and leave the old waterer out for two days.

Where the Farm Basics Stainless falls short

The price is the whole argument. At $19.99 for eight it is about $2.50 a nipple, which is roughly eight times the $0.29 a Hedume costs and more than three times the Eggluuz pack. In ordinary backyard use the plastic bodied nipples last for years, so most keepers are paying that premium against a failure they will never see.

It also ships without a drill bit, and the eighth inch MPT thread needs a hole matched to it. Get that hole wrong in a bucket wall and the metal body does not save you, because the leak is at the plastic.

And metal is not an answer to freezing. Stainless pulls heat out of the small volume of water in the stem faster than plastic does, so if anything an all metal nipple ices up sooner. Below 32 F you still need a heated base under the bucket.

Research based, not hands-on

Assessed on the stated all stainless construction, thread specification and included wing nuts from the listing, and on cost per nipple worked out from the price and the eight piece quantity against the other five packs here.

Recommendation based on: Manufacturer stated material, thread size, mount style and included extras from the live Amazon listing; Cost per nipple comparison against the other five nipple packs in this guide; Published guidance on nipple drinker materials and known plastic body failure modes.

Best for
Keepers who have already had plastic nipple bodies crack at the thread and want the failure point removed.
Skip it if
You are pricing a new system, because a plastic bodied nipple delivers the same water for a fraction of the cost.
The limitation to plan around
Metal conducts heat away faster than plastic, so an all stainless stem is no better in a freeze and arguably worse. It still needs a heated base below 32 F.

5 Best Ready Made Watering Line

DIY Chicken Watering System - 1/2" PVC Tee Fittings and Chicken Waterer Nipples with PVC Pipe, Stainless Steel Hose, Automatic Chicken Waterer Feeder Kit for Chicken, Duck, Quail

MAVGZUL DIY Chicken Watering System - 1/2" PVC Tee Fittings and Chicken Waterer Nip… (MAVGZUL DIY System)

A whole watering line in one box: eight horizontal nipples, tees, 10 lengths of PVC pipe, a hole saw, straps, a shut off valve and a stainless hose. At $5.57 a nipple it is the dearest per nipple here, and the fittings are what you are paying for.

What we liked

  • Everything for a piped run in one order, including 10 PVC pipes, tee fittings, an end cap and eight u-straps with screws
  • Hole saw supplied, so the reservoir connection is cut to the right size
  • Shut off valve included, so you can isolate the line to clean or repair without draining the bucket
  • Stainless steel hose and brass connector between the reservoir and the pipe rather than plain vinyl
  • Horizontal nipples on the tees, so the run sits low and drips fall clear of the pipe

What we did not

  • $5.57 a nipple against $0.29 for a plain horizontal pack, so nearly all the money is fittings you may already own
  • No drill and no bucket are included, so the two things that actually make it work are still a separate purchase
  • A glued and strapped pipe run is fixed in place, so moving the drinkers later means cutting the line and refitting

Key specifications

Colour
Red
Mount Style
Horizontal nipples on 1/2 in PVC tee fittings along a piped run
Pack Quantity
8 nipples with tee fittings
Material
Not stated, PVC pipe with a stainless steel hose and brass connector
Birds Per Nipple
Not stated
Included Extras
Hole saw, brass connector, stainless steel hose, shut-off valve, glue, adapter, tape, 10 PVC pipes, end cap, 8 u-straps with screws. Drill and bucket not included
Listing Note
None

Why the MAVGZUL DIY System wins this category

Because it is the only entry here that arrives as a system rather than as parts. Eight horizontal nipples on half inch PVC tees, 10 lengths of pipe, an end cap, eight u-straps with screws, a hole saw, a brass connector, a stainless steel hose, a shut off valve, glue, an adapter and tape. Building the same run from separate orders is four or five purchases and a lot of guessing about thread sizes.

Two items in that list are worth more than they look. The hole saw is sized for the reservoir connection, which is the one cut in this build that has to be right. And the shut off valve lets you isolate the line to clear a blocked nipple or take the pipe down for cleaning without emptying the bucket over your boots.

The nipples are horizontal, so the pipe run sits low along a wall at bird height. That keeps the reservoir at a sensible height and puts the drips on the ground rather than on the pipe.

Living with the MAVGZUL DIY System

Dry fit the whole run before you glue. Mark where each nipple lands, check it sits slightly above the back of your shortest hen, and make sure you can reach every tee to clean it.

Strap the pipe to something solid. The u-straps and screws are in the box, and a full half inch line plus fittings is heavier than it looks once it is charged with water.

Cut the reservoir hole with the supplied hole saw and fit the brass connector and stainless hose. Then close the shut off valve, fill the bucket, and open the valve with the line over grass rather than bedding while you check every joint.

Teach the birds afterwards. Tap a pin until a drop hangs and hold it up to a beak. Leave the old waterer out for 48 hours.

Where the MAVGZUL DIY System falls short

The price per nipple is stark. $44.55 for eight nipples is $5.57 each, the highest figure in this guide by a wide margin. That is not the price of the nipples, it is the price of the pipe, the hole saw, the valve and the straps. If those are already in your shed, you are paying an enormous premium for eight drinkers you could buy for a couple of dollars.

The exclusions matter too. MAVGZUL states plainly that no drill and no bucket are included, and those are the two things the system does not work without. Anyone reading this as a complete watering solution will be short a reservoir on the day it arrives.

And a glued, strapped run is a permanent installation. That is fine for a fixed coop and a poor fit for a tractor or anything you move around the yard, where drilled buckets stay flexible.

Research based, not hands-on

Assessed on the stated parts list, mount style and materials from the listing, on what the listing explicitly excludes, and on cost per nipple worked out from the price and the eight nipple quantity against the other five packs.

Recommendation based on: Manufacturer stated parts list, mount style, materials and exclusions from the live Amazon listing; Cost per nipple comparison against the other five nipple packs in this guide; Published guidance on PVC watering line assembly and reservoir connection.

Best for
Anyone building a piped watering run along a coop wall who would rather order one box than source ten separate parts.
Skip it if
You already have PVC offcuts, a hole saw and straps in the shed, because then you are buying eight nipples at a very high price.
The limitation to plan around
The parts list is long and the drill and reservoir are missing from it. Read the included extras against what is in your shed before you decide this is the convenient option.

6 Best for a Vertical PVC Install

KISEER 30 Pack Automatic Chicken Waterer Poultry Water Nipple Drinker Feeders Hen Duck Screw Style

KISEER 30 Pack Automatic Chicken Waterer Poultry Water Nipple Drinker Feede… (KISEER 30-Pack)

The only screw style nipple here, made to go into the underside of a PVC run or the base of a bucket. At $0.33 each it is close to the cheapest per nipple, and the vertical mount changes where your reservoir and your drips have to sit.

What we liked

  • About $0.33 a nipple, the second lowest cost per nipple in this guide
  • Screw style suits the underside of a PVC pipe, which a horizontal nipple cannot do
  • Thirty nipples covers a long piped run with spares from one order
  • One of only two packs here that states a birds per nipple figure, at three birds per nipple

What we did not

  • The listing says no drip cup is required, and a vertical valve with a column of water above it drips onto whatever sits below the line
  • No material is stated at all, so you cannot tell whether the body is ABS plastic, metal or something else before it arrives
  • Nothing ships with the nipples, no bit, no tees, no gaskets and no tape, and a vertical install is mostly plumbing

Key specifications

Weight
0.1 pounds
Colour
Red
Mount Style
Screw style, installed vertically into PVC pipe or a reducing tee
Pack Quantity
30 nipples
Material
Not stated
Birds Per Nipple
Maker recommends 3 birds per nipple
Included Extras
None, nipples only, maker says no drip cup is required
Listing Note
None

Why the KISEER 30-Pack wins this category

It is the vertical one, and vertical is the right answer for a specific build. If you are running a half inch PVC line along the top of a run and dropping nipples out of its underside, a horizontal side mount will not do the job. The KISEER 30-Pack screws into the bottom of a pipe or a reducing tee, which is exactly the arrangement commercial houses use and a good setup for watering a long run from one reservoir.

Thirty nipples for $9.99 is about $0.33 each, the second lowest cost per nipple in this guide and within a few cents of the cheapest. For a line with a drinker every few feet plus spares, that is the economical way to do it.

KISEER also states a flock figure, three birds per nipple, which is more conservative than the one per four we work to. Only one other pack here states anything at all.

Living with the KISEER 30-Pack

Plan the height before anything else, because this is where vertical differs. The reservoir has to sit above the pipe, and the pipe has to sit above the birds, so you are looking at a bucket on a stand at roughly head height. Give that stand a proper base, because a full 5 gallon bucket is about 42 lb of water.

Keep bedding away from underneath the line. Vertical nipples drip, and the drips fall straight down. Gravel, a paver run or bare ground under the pipe keeps the coop dry. Shavings under a vertical line turn into a wet strip within a week.

Seal every joint and pressure test the line before the birds see it. A leak overhead is worse than a leak at a bucket wall.

Train them the same way. Tap the pin until a drop hangs and hold it to a beak.

Where the KISEER 30-Pack falls short

The no drip cup claim is the one to record and not repeat. KISEER states that no drip cup is required. Vertical nipples drip. That is the mechanical consequence of a valve pointing at the ground with a column of water above it, and it is why drip cups exist as a product at all. Treat the claim as marketing and design the ground under the line accordingly.

The listing also states no material. Every other pack here says stainless steel, ABS plastic or both. KISEER says nothing, so you cannot tell before it arrives what the body is made from.

Nothing ships with it either. No bit, no tees, no gaskets, no tape. You supply all the plumbing, and with a vertical install that plumbing is most of the work.

And the mount style is a commitment. Once you have picked vertical, the reservoir goes up on a stand and stays there.

Research based, not hands-on

Assessed on the stated screw style mount, pack quantity and birds per nipple figure from the listing, on what the listing does not state about material, and on cost per nipple against the other five packs here.

Recommendation based on: Manufacturer stated mount style, pack quantity, birds per nipple figure and drip cup claim from the live Amazon listing; Cost per nipple comparison against the other five nipple packs in this guide; Published guidance on vertical nipple installation and drip behaviour in poultry watering lines.

Best for
Keepers plumbing a vertical PVC line under a raised reservoir, where the pipe runs above the birds.
Skip it if
You want to convert a bucket to sit flat on a block, because a bottom mounted nipple means the bucket has to go up on a stand.
The limitation to plan around
Vertical nipples put the reservoir above head height and every drip lands directly below. Anything under the line, bedding included, ends up wet.

How we compared these nipple waterers

Mount style came first, because it is the decision you cannot undo once the holes are cut.

Horizontal side mount means the nipple threads into the bucket wall, low down, and the bucket sits flat on a block. Vertical screw in means the nipple goes into the base of the bucket or the underside of a pipe, and the reservoir has to be lifted above the birds. Five of these six are horizontal. The KISEER pack is the vertical one.

Then we looked at what ships in the box, because the hole is the second half of the mount spec. Eggluuz includes the matching drill bit and a wingnut. Hedume includes nothing and expects you to drill 8 mm and hand tighten. senylanhxy skips drilling altogether with 15 threaded PVC tees, gaskets and tape. MAVGZUL goes further again with a hole saw, pipe, straps and a shut off valve. Farm Basics ships wing nuts.

Cost per nipple came last, worked out from price and pack quantity: Hedume $0.29, KISEER $0.33, Eggluuz $0.75, senylanhxy $1.20, Farm Basics $2.50, and MAVGZUL $5.57 with all its fittings included.

We also recorded two listing claims that we do not repeat. Eggluuz says its nipples will not gum up or freeze in winter. KISEER says no drip cup is needed. Both are covered below.

What actually matters in a chicken nipple waterer

Mount style, the spec that decides the install

Almost nobody checks this before buying, because both types photograph identically and both are described as automatic poultry drinkers.

Horizontal is the easier life in a coop. The nipple sits in the bucket wall an inch or two above the base, so grit that settles out stays below the valve. The bucket stands flat on a paver or a stack of blocks, which puts the drinkers at back height with no hanging hardware. The angled stem means a drip runs off the front and lands on the ground rather than tracking back under the bucket.

Vertical is the choice when you are plumbing a run rather than filling a bucket. A screw in nipple goes into the underside of a PVC pipe every couple of feet, and one line can water a long house. The price of that is that the reservoir sits above the birds, so the bucket needs a stand at head height, and drips land straight down. Put bedding under a vertical line and you will have a wet patch under every nipple.

The hole you drill

This is where nipple waterers actually fail, and it costs nothing to get right.

A nipple threads into plastic. If the hole is a shade too big, the thread has nothing to bite and the seal never seats. The bucket then weeps a slow trickle all day, every day, and it will not stop. Tape wrapped round the thread buys you a week. The bucket is effectively ruined.

That is the whole case for the Eggluuz 8-Pack. It costs $0.75 a nipple against $0.29 for a Hedume, and the difference buys the correct bit in the same box. If you already own the right size bit, or you are happy to test on a scrap bucket, the cheaper pack is a fine buy.

The alternative is not to drill at all. The senylanhxy Tee Kit gives you 15 nipples already matched to half inch PVC tee fittings with gaskets and tape, so the seal is a threaded joint rather than a hole you cut.

How many nipples, and what the makers say

Two of the six state a figure. KISEER says three birds per nipple. Hedume says four. The other four say nothing at all.

Our working number is one nipple per four birds, and at least two per bucket regardless of flock size. The second nipple is redundancy rather than capacity. A valve that jams shut is a flock with no water, and in summer that is a serious problem within a few hours.

Plastic against stainless

Most of these use a stainless pin in an ABS plastic body. Farm Basics is the exception, all stainless throughout.

Say plainly what that buys. A stainless nipple at about $2.50 each is roughly eight times the price of a Hedume at $0.29, and in ordinary use it does exactly the same job. The case for metal is a specific failure: a plastic body going brittle in hard sun and splitting at the thread. If that has happened to you, buy the metal ones. If it has not, the plastic bodies are not the weak point in your system.

Getting a nipple system running

Set the height first. A bird should reach slightly up to drink, roughly at eye level with the valve, which means the nipple sits a little above the back of your shortest hen. Too low and they stand on the bucket. Too high and the smallest birds go short.

Then teach them. Birds do not find nipples on their own, and this is the step people skip. Tap the pin until a drop hangs on it, hold it to a beak, and let two or three birds get the idea. The rest copy within a day. Leave the old waterer out for 48 hours in the meantime.

Watch the first fill for 10 minutes. Any weeping at a thread shows up straight away, and it is far easier to redrill a bucket on day one than to live with a wet patch all season.

Then plan for winter separately. None of the six nipples here is heated, and the metal stem is the first thing to freeze. A heated base under the bucket or a submersible de-icer is the answer, and it is a different purchase.

Final recommendation

The Eggluuz 8-Pack is the one to buy for a bucket. It is horizontal, so the bucket sits flat on a block and you use nearly all the water, and it is the only pack here that ships the matching drill bit and a wingnut. That bit is the difference between a bucket that seals and a bucket that weeps for the rest of its life. Ignore the listing line about not freezing in winter, because no open nipple can do that.

Three alternates. If you are kitting out a large flock or several buckets, the Hedume 50-Pack is $0.29 a nipple, the cheapest per nipple here, and you supply your own 8 mm bit. If you do not want to drill at all, the senylanhxy Tee Kit gives you 15 nipples on threaded PVC tees with gaskets and tape, so the seal is a fitting rather than a hole. And if you are plumbing a vertical PVC line rather than filling a bucket, the KISEER 30-Pack is the screw style built for it, though the maker's claim that no drip cup is needed does not match how vertical nipples behave.

The MAVGZUL DIY System is the whole watering line in one box at $5.57 a nipple, which is the dearest per nipple here and reasonable if you want the hole saw, pipe, straps and shut off valve rather than sourcing them. The Farm Basics Stainless is the answer to split plastic bodies and nothing else.

Questions people ask before buying

What is the difference between horizontal and vertical nipples?

It decides where the water can sit. A horizontal side mount threads into the wall of a bucket an inch or two above the base, so the bucket can stand flat on a block at bird height and you use nearly all the water in it. A vertical screw in nipple goes into the bottom of the bucket or the underside of a PVC pipe, so the reservoir has to be raised above the birds and every drip falls on the bedding. For a bucket in a coop, horizontal is the easier install and the drier one.

How many nipples do I need for my flock?

Plan on one nipple per four birds and fit at least two per bucket. Only two makers here state a figure at all: KISEER says three birds per nipple and Hedume says four, and the other four packs say nothing. The reason for the second nipple is not supply, it is failure. A single valve that jams shut leaves the flock with no water at all, and you may not notice until the evening. Two nipples on the same bucket makes that a nuisance rather than an emergency.

Will nipple waterers freeze in winter?

Yes. Any open nipple holds a small amount of water in a thin metal stem exposed to the air, and that stem freezes at 32 F with no heat behind it. The Eggluuz listing says its nipples will not gum up or freeze in winter. We record that claim and we do not repeat it, because no unheated nipple can hold it. If your winters go below freezing, plan on a heated base or a submersible de-icer under the bucket as a separate purchase.

How do I stop a nipple leaking after I install it?

Drill the right hole. This is the failure that ruins nipple installs, and it happens at the first step. A hole even slightly oversize in a bucket wall will weep constantly, the bedding underneath stays wet, and no amount of tape or sealant reliably fixes it once the plastic is cut. Use the bit that matches the thread, which is why the Eggluuz pack shipping its own bit matters. If you are drilling 8 mm by eye for a Hedume nipple, test on a scrap bucket first.

Do chickens work out how to use nipples on their own?

Mostly not, and this is what owners learn after buying. A nipple looks like nothing a bird recognises, so it gets ignored while the flock stands at the old waterer. Tap the pin with your finger until a drop hangs on it, then hold the drop up to a hen's beak so she gets a taste. Two or three birds learning is usually enough, because the rest copy. Leave the old open waterer out for 48 hours so nobody goes short while they work it out.

Are stainless steel nipples worth the extra money?

Only if split plastic bodies are a failure you have actually had. The Farm Basics stainless nipple works out at about $2.50 each, roughly eight times the $0.29 a Hedume costs, and it does the same job in the same place. Most of the packs here use a stainless pin in an ABS plastic body, and that combination lasts years in normal use. If your buckets sit in hard sun and you have watched plastic go brittle and crack at the thread, the all metal build is a reasonable answer to a real problem.

Why you can trust this guide

Written by
Sam Reddick, Lead gear reviewer, Chicken Geek. Specialist areas: Coop design and predator proofing, Feeding and watering systems, Cold-weather flock management, Incubation and brooding.
Fact checked by
Marta Voss
Published
August 8, 2026 · Last updated August 8, 2026 · Products and links rechecked August 8, 2026
How we picked
Each pack was compared on mount style first, because horizontal and vertical dictate where the reservoir sits and where drips land, then on whether the matching drill bit and fittings are included, on the stated material, on the maker's birds per nipple figure, and on cost per nipple worked out from the price and the pack quantity.
Evidence used
None of the 6 products on this page were sent to us or bought for a hands-on test. Every recommendation here is research based: manufacturer specifications, listed dimensions and materials, owner feedback at volume, and comparison against equipment our team has owned. Each review states this again above the buy button so you are never guessing which kind of evidence sits behind a pick.
Editorial standards
No brand pays for placement, and no manufacturer sees this page before it goes live. Read our editorial policy and testing method.
Affiliate disclosure
Chicken Geek is reader supported. We earn a commission from qualifying purchases made through links on this page, at no extra cost to you, and no brand has paid for a placement or an award here.

About the author

Monogram avatar with the initials S R

Sam Reddick

Lead gear reviewer, Chicken Geek

Sam has kept a backyard laying flock for eleven years, through two coop rebuilds, one very determined raccoon and several winters cold enough to freeze a waterer solid overnight. He writes the buying guides at Chicken Geek and is responsible for how products get compared.

  • Eleven years keeping a mixed laying flock of 8 to 14 birds
  • Has built, bought and replaced six different coops
  • Runs the product comparison framework used across Chicken Geek
  • Reads manufacturer manuals, spec sheets and warranty terms before every recommendation
